The Ubiquiti airMAX Sector Antenna 16dbi 120 Degree is often used in short range installation within WISP networks to connect client devices back to the main the network. This sector has a wide 120 Deg' beam to cover a larger, with only 16dBi gain this is best used in close range.
To get the best from this sector we recommend using the Rocket M5 in order to achieve the most reliable PTMP Links.
World Class Antenna Designs:
Next-generation technology achieves gain, cross-pol isolation, and beamshaping characteristics rivaling the highest quality cellular carrier basestation antennas in the world. Instantly pair with Rocket M5 to create a powerful AirMax 2x2 MIMO PtMP BaseStation. Rocket mount and weatherproof RF jumpers included.
Rocket M Seamlessly Integrates with AirMax BaseStation Sectors:
Rocket M and AirMax BaseStation/Rocket Antennas have been designed to seamlessly work together. Installing Rocket M on AirMax BaseStation/Rocket Antennas requires no special tools, you simply snap it into place with the mount provided with the Antennas.
Frequency Range: 5.10-5.85 GHz
Gain: 15-16 dBi
Polarization: Dual Linear
Cross-Pol Isolation: 22dB min
Max VSWR: 1.5:1
Hpol Beamwidth (6dB): 137 deg.
Vpol Beamwidth (6db): 118 deg.
Elevation Beamwidth: 8 deg.
Electrical Downtilt: 4 deg.
ETSI Specification: EN302 326 DN2
Dimensions: 367x63x41mm
Weight: 1.1Kgr
Windloading: 120mph
